eBike Overview
eBike Type: Commuter Bike
The style of riding intended for this bike
Released: 2024
The bike was released 2 years ago
Screen
Bosch Intuvia 100
Lights Included
No
Weight (inc battery): 28.8 kg
The website average for electric bikes is 22.99 kg. This electric bike is 5.80 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
XS: 152-163 cm, S: 161-171 cm, M: 169-180 cm, L: 178-190 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Cross X 17 Disc 32 h rims on Shimano hubs
Wheelset Size
700c
Tires
Front: Schwalbe Energizer Plus Tour 700x55c, Rear: Schwalbe Energizer Plus Tour 700x55c
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
128 kg (282.2 lbs)
Drivechain Details
Groupset details
Alivio
Drivechain type
Chain drive
Shifters
Shimano Alivio SL-M 3100 9-speed
Amount of gears
9 Gears
Rear Derailleur
Shimano Alivio RD-M 3100 SGS 9-speed
Front Derailleur
None
Cassette
Shimano CS HG 400 11-36 T
Cranks
Miranda 172.5 mm with a 38 T chainring
Chain
KMC E 9 s NPBK
Bottom Bracket
Integrated within the Bosch motor unit
Brakes
Brakes
Shimano hydraulic disc brakes
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
180 mm front / 160 mm rear
Shifters
Shimano Alivio SL-M 3100 9-speed
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
