eBike Overview
eBike Type: Commuter Bike
The style of riding intended for this bike
Released: 2023
The bike was released 3 years ago
Screen
Purion Display
Lights Included
No
Weight (inc battery): 26.4 kg
The website average for electric bikes is 23.00 kg. This electric bike is 3.39 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
S: 158-171 cm, M: 168-180 cm, L: 178-189 cm, XL: 186-199 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Cross X 17 Disc 32 h rims with Shimano hubs (HB-TX 50/FH-TX 50 or MT 200 variant)
Wheelset Size
700c
Tires
Front: Schwalbe Energizer Active Plus 700x50c, Rear: Schwalbe Energizer Active Plus 700x50c
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
128 kg (282.2 lbs)
Drivechain Details
Groupset details
Alivio
Drivechain type
Chain drive
Shifters
Shimano Alivio 3100 9-speed
Amount of gears
9 Gears
Rear Derailleur
Shimano Alivio 3100
Front Derailleur
None
Cassette
Shimano CS HG 400, 11-36 T
Cranks
Miranda 172.5 mm with a 38 T Chainflow chainring
Chain
KMC E 9 s NPBK
Bottom Bracket
Bosch Integrated (standard for mid-drive units)
Brakes
Brakes
Shimano hydraulic disc brakes
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
Shimano BR-M 200
Shifters
Shimano Alivio 3100 9-speed
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
