eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2025
The bike was released 1 years ago
Screen
Bosch Intuvia 100 + LED Remote
Lights Included
No
Weight (inc battery): 26 kg
The website average for electric bikes is 22.99 kg. This electric bike is 3.00 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
S: 160–170 cm, M: 168–178 cm, L: 175–185 cm, XL: 183–195 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Schürmann Yak 25 aluminium double-walled rims
Wheelset Size
27.5 inch
Tires
WTB Groov-E, w/ reflective stripe, 60TPI 62-584
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
150 kg (330.7 lbs)
Drivechain Details
Groupset details
CUES
Drivechain type
Chain drive
Shifters
Shimano CUES SL-U 4010-9 R (Rapidfire Plus trigger shifter) or Shimano Alivio trigger switch
Amount of gears
9 Gears
Rear Derailleur
Shimano CUES RD-U 4000-GS
Front Derailleur
None
Cassette
Shimano CUES CS-LG 300-9 Linkglide (or Shimano HG 200) with a 11-36 teeth gear range
Cranks
Miranda Kies forged steel matching arms paired with a 38-teeth chainring
Chain
KMC e 9 S
Bottom Bracket
Integrated
Brakes
Brakes
Hydraulic Disc
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
160 mm Tektro or 180 mm Alhonga rotors
Shifters
Shimano CUES SL-U 4010-9 R (Rapidfire Plus trigger shifter) or Shimano Alivio trigger switch
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
