eBike Overview
eBike Type: Mountain Bike
The style of riding intended for this bike
Released: 2025
The bike was released 1 years ago
Screen
Bosch Kiox 300
Lights Included
No
Weight (inc battery): 23.35 kg
The website average for electric bikes is 22.99 kg. This electric bike is 0.35 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
S: 160–170 cm, M: 168–178 cm, L: 175–185 cm, XL: 183–195 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
DT Swiss H 1900 SPLINE e-bike wheelset (aluminum rims, tubeless-ready)
Wheelset Size
29 inch
Tires
Maxxis Minion DHF II 65-622
Frame Info
Frame Material
Carbon Fiber
Suspension Type
Front and Rear suspension
Foldable Frame
No
Max Payload
135 kg (297.6 lbs)
Drivechain Details
Groupset details
Eagle AXS, GX Eagle Transmission
Drivechain type
Chain drive
Shifters
SRAM AXS Pod Controller
Amount of gears
12 Gears
Rear Derailleur
SRAM GX Eagle AXS Transmission
Front Derailleur
None
Cassette
SRAM GX Eagle XS-1275 (12-speed, 10-52 teeth gear range)
Cranks
Haibike Components The Cranks ++ aluminum e-crank arms paired with a SRAM 36 T direct-mount chainring
Chain
SRAM GX Eagle T-Type Flattop chain
Bottom Bracket
Integrated (the spindle interfaces directly with the internal bearings of the Bosch Gen 5 mid-drive motor casing)
Brakes
Brakes
Magura MT5
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
220 mm front rotor and 200 mm rear rotor
Shifters
SRAM AXS Pod Controller
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
