eBike Overview
eBike Type: Mountain Bike
The style of riding intended for this bike
Released: 2025
The bike was released 1 years ago
Screen
Yamaha A2 Display
Lights Included
No
Weight (inc battery): 26 kg
The website average for electric bikes is 22.99 kg. This electric bike is 3.00 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
SM: 158–171 cm, MD: 168–180 cm, LG: 178–189 cm, XL: 186–199 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Rodi Tryp 30 double-walled aluminium rims laced to Shimano MT 400-B Boost hub assemblies
Wheelset Size
29 inch
Tires
Schwalbe Nobby Nic Performance 60-622
Frame Info
Frame Material
Aluminium
Suspension Type
Front and Rear suspension
Foldable Frame
No
Max Payload
120 kg (264.6 lbs)
Drivechain Details
Groupset details
microSHIFT Advent X
Drivechain type
Chain drive
Shifters
Shimano CUES U 6000, Rapidfire Plus 10-speed trigger shifter
Amount of gears
10 Gears
Rear Derailleur
Shimano CUES U 6000
Front Derailleur
None
Cassette
Shimano CUES LG 300, 10-speed (11-48 tooth gear range)
Cranks
Haibike Components The Crank ++, custom forged aluminium arms with a steel 38 T chainring
Chain
Shimano LG 500 Linkglide-specific 10-speed chain
Bottom Bracket
None (integrated)
Brakes
Brakes
Shimano Hydraulic Disc
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
203 mm front and rear
Shifters
Shimano CUES U 6000, Rapidfire Plus 10-speed trigger shifter
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
