eBike Overview
eBike Type: Mountain Bike
The style of riding intended for this bike
Released: 2024
The bike was released 2 years ago
Screen
Yamaha Side Switch
Lights Included
No
Weight (inc battery): 20 kg
The website average for electric bikes is 23.00 kg. This electric bike is 3.01 kg under the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
Kids XS: 115–135 cm, Kids S: 130–150 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Rodi FW Disc hollow-profile aluminium rims laced to Haibike Alu Naben hubs via black steel spokes
Wheelset Size
24 inch
Tires
Schwalbe Billy Bonkers 50-507
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
80 kg (176.4 lbs)
Drivechain Details
Groupset details
CUES
Drivechain type
Chain drive
Shifters
Shimano Altus M 2010 rapidfire pod shifter
Amount of gears
9 Gears
Rear Derailleur
Shimano Altus M 2000
Front Derailleur
None
Cassette
Sun Race CSM 90 9-speed 11-36T
Cranks
Haibike The Crank ++, standard steel chainring with an alloy arm assembly
Chain
KMC e 9 S
Bottom Bracket
Integrated within the Yamaha PW-TE mid-drive motor unit housing
Brakes
Brakes
Tektro Hydraulic Disc
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
Tektro HD-M 282 (front and rear)
Shifters
Shimano Altus M 2010 rapidfire pod shifter
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
