eBike Overview
eBike Type: All Terrain
The style of riding intended for this bike
Released: 2026
The bike was released this year
Screen
Bosch CX Smart System
Lights Included
No
Weight (inc battery): 28 kg
The website average for electric bikes is 22.99 kg. This electric bike is 5.00 kg over the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
SM: 150–170 cm, MD: 168–178 cm, LG: 176–186 cm, XL: >184 cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Schürmann YAK Disc 25-584 32-hole double-wall alloy rims
Wheelset Size
27.5 inch
Tires
Schwalbe Johnny Watts w/ reflective line, 60-584
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
150 kg (330.7 lbs)
Drivechain Details
Groupset details
XT, Deore
Drivechain type
Chain drive
Shifters
Shimano Deore SL-M 6100-R Rapidfire Plus trigger shifter (right side)
Amount of gears
12 Gears
Rear Derailleur
Shimano Deore XT RD-M 8100-SGS
Front Derailleur
None
Cassette
Shimano Deore CS-M 6100-12 10-51 T
Cranks
Miranda Crius ISIS alloy crank arms fitted with a 38 T steel chainring
Chain
Shimano Deore CN-M 6100 12 s
Bottom Bracket
Integrated (The bottom bracket spindle is a structural piece built directly into the Bosch Performance Line CX motor unit)
Brakes
Brakes
Magura Hydraulic Disc
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
203 mm front and rear
Shifters
Shimano Deore SL-M 6100-R Rapidfire Plus trigger shifter (right side)
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
