eBike Overview
eBike Type: Commuter Bike
The style of riding intended for this bike
Released: 2025
The bike was released 1 years ago
Screen
Cadence Sensor
Lights Included
No
Weight (inc battery): 20.41 kg
The website average for electric bikes is 22.99 kg. This electric bike is 2.59 kg under the average. Total bike weight may vary depending on frame size.
Sizing & Geometry
Min / Max Rider Height
XS: <167 cm, SM: 165–175 cm, MD: 173–184 cm, LG: 182–192 cm, XL: 190+ cm
Folded Dimensions
Unknown
Wheel & Tire Details
Wheelset Name
Shining double-wall, disc-specific 36-hole alloy rims, laced with DT Swiss Champion 13 g heavy-duty spokes to a Formula front hub and the Bafang rear motor hub
Wheelset Size
700c
Tires
Schwalbe Big Ben, 700x50c
Frame Info
Frame Material
Aluminium
Suspension Type
Front Suspension
Foldable Frame
No
Max Payload
136 kg (299.8 lbs)
Drivechain Details
Groupset details
microSHIFT Mezzo, microSHIFT M26
Drivechain type
Chain drive
Shifters
micro SHIFT TS 39-7 (7-speed rapid-fire trigger shifter)
Amount of gears
7 Gears
Rear Derailleur
micro SHIFT RD-M 26 L
Front Derailleur
None
Cassette
Sunrace M 40 11-34 T
Cranks
Samox alloy crankarms fitted with a 38 T single chainring
Chain
KMC Z 7
Bottom Bracket
Tange Seiki LN 3912 spindle housing featuring an integrated Darfon Cadence Sensor
Brakes
Brakes
Tektro HD Hydraulic Disc
Brake Type: Hydraulic Disc Brake
Hydraulic operated discs brakes (Very good)
Brake Rotors
160 mm front and rear
Shifters
micro SHIFT TS 39-7 (7-speed rapid-fire trigger shifter)
Other Components
Saddle
Unknown
Handlebars
Unknown
Bar Tape
Unknown
Manufactures Info
Worldwide Shipping:
Warranty: None
Limited warranty website average: 3.12 years
