Bike Info
Worldwide Shipping: Yes
Delivery across the globe!
Warranty: Lifetime
Limited warranty website average: 3.12 years
Released: 2025
The bike was released 1 years ago
Bike Type: Road
The style of riding intended for this bike
Bike Spec
Weight: 7.7 kg
The website average for Road bikes is 8.56 kg. This bike is 0.87 kg under the average. Total bike weight may vary depending on frame size.
Groupset
Shimano Ultegra Di2
Wheelset
Brake Type: Disc Brake
Welcome to the future!
Frameset Material
Carbon Fiber
Max Tire Size: 32 mm
This is the max tire size you can use
UCI Approved: Yes
You can use for official races
Sizing & Geometry
Frame Sizes
47 50 52 54 56 59This frame comes in 6 sizes, this is 0.44 more sizes than the website average.
Sizing & Geometry
Frame measurements and sizing vary by bike size. Measurements are shown for each available frame size.
Swipe across to view all sizes.
| Geometry | XXS | XS | S | M | L | XL |
|---|---|---|---|---|---|---|
| Sizing | ||||||
| Wheel size | 700c | 700c | 700c | 700c | 700c | 700c |
| Frame geometry | ||||||
| Stack (mm) | 512 | 517 | 529 | 557 | 571 | 593 |
| Reach (mm) | 373 | 377 | 384 | 395 | 400 | 409 |
| Effective top tube (mm) | 520 | 535 | 545 | 560 | 575 | 590 |
| Seat tube (mm) | 470 | 500 | 520 | 540 | 560 | 590 |
| Head tube (mm) | 100 | 110 | 120 | 140 | 155 | 175 |
| Standover (mm) | 741 | 768 | 788 | 810 | 829 | 857 |
| Handling | ||||||
| Head angle (°) | 71 | 72 | 73 | 73.50 | 73.50 | 74 |
| Seat angle (°) | 74.50 | 74 | 74 | 73.50 | 73 | 73 |
| Chainstay (mm) | 408 | 408 | 408 | 408 | 408 | 408 |
| Wheelbase (mm) | 973 | 980 | 982 | 992 | 1,002 | 1,012 |
| Fork offset (mm) | 45 | 45 | 45 | 45 | 45 | 45 |
Frame Details
Frame Weight
This frame weighs 950g
Frame Material
Carbon Fiber
Forks
REACTO CF5 IV DISC
Fork Material
The forks are made from Carbon Fiber
Cables: Internally Routed
Routed through bars, stem and frame
Axel Type: Thru-axle
How the wheels are secured to the frame
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How the calipers are mounted
Integrated bar and stem: Yes
The bar and stem are integrated
Drivechain Details
Groupset name
Shimano Ultegra Di2
Electric Groupset: Yes
This bike has electric gears
Shifters
Shimano Ultegra disc Di2
Front Derailleur
Shimano Ultegra Di2 (FD-R8150, braze-on).
Rear Derailleur
Shimano Ultegra Di2
Cassette
Shimano Ultegra CS-R8101 (or CS-R8100 depending on batch delivery).
Cranks
Shimano Ultegra R8100 (Scaled 165mm–175mm)
Power Meter: No
This bike doesn't have a power meter
Bottom Bracket
BB86,5 bottom bracket standard
Chain
Shimano XT/Ultegra CN-M8100-12.
Battery
Unknown
Wheel & Tire Details
Wheelset Name
Reynolds BL60 Expert DB, 100x12mm width front hub
Front Wheel Depth
60mm
Rear Wheel Depth
60mm
Tires
Continental Grand Prix 5000S TR
Tire Type
Clincher
Max Tire Size: 32 mm
This is the max tire size you can use
Brakes
Brake Type: Disc Brake
Welcome to the future!
Brake Mount: Flat Mount
How these disc brakes are mounted
Brakes
Ultegra Hydraulic disc
Brake Rotors
160 mm front / 160 mm rear Shimano RT-CL800 Centerlock rotors
Other Components
Saddle
Prologo Scratch M5
Seatpost
MERIDA TEAM CW
Handlebars
Vision Metron 5D ACR EVO
Bar Tape
MERIDA ROAD Expert
